Hipot Tester TongHui TH9111A (5kVAC - 6kVDC)

Features TongHui TH9111A

■ High power: AC 5kV / 100mA / 500VA output

■ High security:

 High-voltage floating output design, in line with the safety requirements of EU standards EN50191 (only TH9110)

 Electric shock protection function

■ High resolution: 7 inch 800 × 480 dots, TFT-LCD display

■ Brand-new operation interface, Chinese and English menu

■ ARC detection function

■ Contact check function (OSC)

■ Breakdown voltage test function

■ One-key screen capture function

■ One-key recording function

■ Rear panel output function to facilitate automated production line testing

■ Storage: 100 files, up to 50 steps per file

Application TongHui TH9111A

■ Winding devices

 Transformers, generators/motors and other products needing high-power withstand voltage test and analysis, such as different types of motor stator, rotor and other high parasitic capacitance products

■ Electronic components

 Capacitors, coils, cores, choke coils, filters and so on

■ Electrical products

 Household appliances, information products, audio-visual equipment, electric heating appliances, lighting equipment

■ Non-electrical products

 Withstand voltage and insulation resistance test for wire, non-woven fabric, insulation materials and so on

■ New energy automobile

■ Automated test system

■ Medical equipment
